2205 Stainless steel pipe Widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial transport pipelines and mechanical structural components. In addition, when the bending and torsional strength are the same, the weight is lighter, so it is also widely used in manufacturing mechanical parts and engineering structures. It is also often used in the production of conventional weapons, barrels, shells and so on

About 2205 duplex seamless stainless steel tube

2205 duplex stainless steel pipes have excellent mechanical properties, corrosion resistance and weldability. They are widely used in petroleum and natural gas industry, marine engineering, chemical industry and other industries. At present, the length of oil and gas pipelines laid with duplex stainless steel materials in petroleum and natural gas industry has exceeded 850Km, and most of them are 2205 duplex stainless steel seamless pipes (some are S31803 duplex stainless steel pipes and 2507 duplex stainless steel pipes). Because of the strong corrosiveness of natural gas medium, 2205 duplex stainless steel materials are used in high-pressure pipelines of West-East Gas Transmission Project.

Application for 2205 seamless

Neutral chloride environment ,Refining Industry,Petrochemical and Chemical Industries,Pipeline for chemical industry ,Petroleum and Gas Industry - Pulp and Paper Industry - Chemical Fertilizer Industry - Urea Industry - Phosphate Fertilizer Industry - Seawater Environment - Energy and Environmental Protection Industry - Light Industry and Food Industry - Equipment of Food and Pharmaceutical Industry - High Strength Structural Components etc.

Chemical composition and Physical property

Grade	C(%)	Si(%)	Mn(%)	Cr(%)	P(%)	S(%)	N（%)	Ni(%)	Mo(%)
2205	≤0.30	≤1.00	≤2.00	21.00-23.00	≤0.040	≤0.020	≤0.20	4.5-6.5	2.5-3.5

Grade	TS(Mpa)	YS(Mpa)	EL(%)
2205	≥620	≥205	≥25

Standard specifications for stainless steel pipe

Inch	DN (mm)	OD (mm)	SCH5S	SCH10S	SCH10	SCH20	SCH30	SCH40	SCH60	SCH80	SCH100	SCH120	--
1/8	DN6	10.3		1.24				1.73		2.42
1/4	DN8	13.7		1.65				2.24		3.02
3./8	DN10	17.1		1.65				2.31		3.2
1/2	DN15	21.3	1.65	2.11				2.77		3.73
3/4	DN20	26.7	1.65	2.11				2.87		3.91
1	DN25	33.4	1.65	2.77				3.38		4.55
1 1/4	DN32	42.2	1.65	2.77				3.56		4.85
1 1/2	DN40	48.3	1.65	2.77				3.68		5.05
2	DN50	60.3	1.65	2.77				3.91		5.54
2 1/2	DN65	73.0	2.11	3.05				5.16		7.01
3	DN80	88.9	2.11	3.05				5.49		7.62
3 1/2	DN90	101.6	2.11	3.05				5.74		8.08
4	DN100	114.3	2.11	3.05				6.02		8.58		11.13
5	DN125	141.3	2.77	3.4				6.55		9.53		12.7
6	DN150	168.3	2.77	3.4				7.11		10.97		14.27
8	DN200	219.1	2.77	3.76		6.35	7.04	8.18	10.31	12.7	15.09	18.26
10	DN250	273.1	3.40	4.19		6.35	7.8	9.27	12.7	15.09	18.26	21.44
12	DN300	323.9	3.96	4.57		6.35	8.38	10.31	14.27	17.48	21.44	25.4
14	DN350	355.5	3.96	4.78	6.35	7.92	9.53	11.13	15.09	19.05	23.83	27.79
----
