The H in 304H refers to high temperature. High carbon content is the guarantee of high temperature strength. GB150 requires that when austenitic steel is used above 525 degrees, the carbon content is not less than 0.04%. Carbides are strengthening phases, especially high temperature strength. Better than pure austenite.
Lower carbon content minimizes the amount of carbides precipitated in the heat affected zone near the weld, and the precipitation of carbides may lead to intergranular corrosion (welding corrosion) of stainless steel in some environments.
Contact:
Mr Jarven
Tel: +86 185 6351 8078 ( WhatsApp / Wechat / Telegram)
Wechat: AF18563518078
Email: [email protected]
TikTok : aofeng.metal
304H stainless steel. The internal branch of 304 stainless steel has a carbon mass fraction of 0.04% to 0.10%, and its high temperature performance is better than that of 304 stainless steel.
Chemical Composition and Mechanical Property
Grade | C(%) | Mn(%) | P(%) | S(%) | Si(%) | Cr(%) | Ni(%) |
304H | 0.04-0.1 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00-20.00 | 8.00-15.00 |
Grade | Yield Strength (Mpa) | Yield Strength (Mpa) | 50mm Elongation (%) | Brinell hardness | Rockwell hardness | Cold Bend |
304H | ≥515 | ≥205 | ≥40 | ≥201 | ≥92 | No Requirement |
